| Quantity: | |
|---|---|
Basic Info.
| Mesh Form | External Engaged | Tooth Flank | Straight Tooth |
| Tooth Curve | Involute | Power | Hydraulic |
| Type | Normal Line Gear Pump | Applications | Machinery Manufacturing |
| Certification | ISO | Characteristic | Hard |
| Weight | 18kg | Max. Pressure | 25MPa |
| Max. Speed | 2500r/Min | Volumetric Efficiency | Over 92% |
| Color | Black | Rated Pressure | 23 MPa |
| Transport Package | Bag, Carton, Pallet | Specification | 27× 16× 14.2 |
| Trademark | HGLT | Origin | Shandong China |
| HS Code | 8413602290 | Production Capacity | 10000/Year |
