Basic Info.
| Model NO. | GLKV25 | Drive | Hydraulic |
| Type | Directly Operated Type | Model No | Glkv25 |
| Material | Cast Iron 450 | Working Temperature | -30 to 80ºC |
| Maximum Work Pressure | 25MPa | OEM/Ode | Yes |
| Application | Construction Machinery, Agricultural Equipment | Support for Customization | Yes |
| Warranty | 1 Year | Power | Pneumatic |
| Color | Red, Black or Customized | Oil Port | M22*1.5 |
| Connection Mode | Internal Thread | Rated Flow | 350L/Min |
| Max Pressure. | 22MPa | Weight | 14.9kg |
| Transport Package | Cartonbox | Specification | 39cm*11cm*16cm |
| Trademark | HGLT | Origin | Shandong China |
| HS Code | 8412299090 | Production Capacity | 20000/Year |
Packaging & Delivery
| Package Size | 39.00cm * 11.00cm * 16.00cm |
| Package Gross Weight | 14.900kg |
Product Description
All oil ports, safety valves and check valves are centrally arranged on the valve body, which is compact in structure and convenient for pipeline layout
The safety valve adopts the combination structure of pressure control cone valve and unloading slide valve, which has good opening and closing characteristics and can reduce the heat loss due to large flow overflow
The circuit is provided with a pressure outlet, which can be used as an oil source for subsequent hydraulic components
